50 SX Mini – 2023

£3,870.00

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry Apply for Finance Finance Calculator

Model Description


The only thing ‘mini’ about the 2023 KTM 50 SX MINI, is its size.
Although small, it is a true READY TO RACE motocross machine, which like
its bigger sibling, is produced with top-quality components, real
race-bred input, and race-winning legacy. It goes without saying that
the KTM 50 SX is the only choice when stepping into the world of MX,
bringing even the youngest riders up to the starting gate.

ENGINE

This little ripper of an engine features a high-performance cylinder, exhaust pipe and reed intake system, which are perfectly arranged for maximum performance, setting the standard in the highly competitive 50 cc class.

CYLINDER HEAD
Engineered to withstand anything a budding young racer can throw at it, this high performance cylinder provides the goods in the highly contested and highly competitive 50 cc class.

CLUTCH
The KTM 50 SX MINI features a centrifugal multi-disc automatic clutch, which provides manageable acceleration for any young beginner. By simply twisting the throttle, young riders can experience the full READY TO RACE world of KTM. Plus, it can be adjusted to the specific requirements of the track and the rider in minutes and without any special tools.

AUTOMATIC TRANSMISSION
The centrifugally controlled, multi-disc automatic clutch developed by KTM delivers easily controllable acceleration and makes riding the KTM 50 SX MINI as easy as twisting the throttle. Furthermore, it can still be quickly and easily adjusted to the specific requirements of both track and rider using the “KTM clicker system” – in a matter of seconds and with no special tools required.

POWER REDUCTION KIT
For those future stars who are still absolute beginners, the engine power can be reduced using a kit from the PowerParts program. Afterall, we all had to start somewhere.

COOLING
Like the full-size KTM SX range, the KTM 50 SX MINI has a liquid cooling system, which even cools the crankcase. This is supported by large radiators providing outstanding heat dissipation, for remarkable reliability.

EXHAUST
The exhaust system was designed to perfectly match the characteristics of the engine, ensuring maximum output and a smooth power delivery over the entire rev range.

FRAME
This modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability at speed.

WHEELS
Like the full-size KTM Factory racers, the 2023 KTM 50 SX MINI is fitted with lightweight, black anodized, aluminum rims which provide the highest strength and durability for any eventuality. These are wrapped in new MAXXIS MX-ST tires, to provide unmatched traction on any surface.

FRONT SUSPENSION
The KTM 50 SX MINI boasts a modern WP 35 XACT upside-down fork. The upside-down front fork with a 35 mm tube diameter and 100 mm of travel ensures small riders feel comfortable, while enjoying outstanding comfort, damping characteristics and directional stability.

REAR SUSPENSION
The high quality WP XACT shock absorber is linked directly to the swingarm, providing excellent damping performance. It is fully adjustable, meaning you can set the damping perfectly to suit the rider’s preference and track conditions. The shock absorber allows for 147 mm of rear wheel travel.

BRAKES
The KTM 50 SX MINI is fitted with front and rear hydraulic brakes by FORMULA, combined with lightweight wave discs that are easy to control even for the youngest riders, helping to build their confidence, and teaching them correct brake control.

FUEL TANK
Don’t let its meager 2.1 litre fuel capacity fool you – the 2023 KTM 50 SX MINI is no slouch when it comes to going full race distance.

SEAT
Providing the perfect blend of grip, durability and comfort, the 2023 KTM 50 SX MINI seat does everything you’d expect it to, while showing off it’s its undeniable READY TO RACE and ‘orange’ heritage.

HANDLEBAR
The KTM 50 SX MINI uses a perfectly shaped handlebar made from a high-quality aluminum alloy. It provides a great feeling of control for the rider, helping with overall stability. A pad around the center brace also protects the rider from hard knocks.

FOOTPEGS
The KTM 50 SX MINI has “”no-dirt” footpegs, which have a simple but effective self-cleaning system that expels mud and soil to prevent excess dirt build-up, with a spring that ensures the footpegs return to their original position, providing complete control in all conditions.

DECALS
The 2023 KTM 50 SX features the latest in-mold graphics, with a bold orange black and purple design that perfectly sets off the factory-look orange frame, orange seat and race-sharpened bodywork.

Finance Calculator

Model Specification


  • Engine
    Engine Type

    Single cylinder, 2-stroke

    Displacement

    49 cc

    Starter

    Kickstarter

    Transmission

    Single gear automatic

    Clutch

    Centrifugal clutch (adjustable)

    ABS System

    Engine Management System

  • Dimensions
    Bore

    39.5 mm

    Stroke

    40 mm

    Ground Clearance (unloaded)

    184 mm

    Seat Height

    558 mm

    Weight (No Fuel)

    40 kg

  • Frame
    Frame

    Chrome-molybdenum steel central-tube frame

    Chain

    1/2 x 3/16

    Steering Head Angle

    67.4 degrees

    Tank Capacity

    2.1 litres

  • Suspension
    Front Suspension

    XACT 35 WP USD Fork 35 mm

    Rear Suspension

    XACT WP shock absorber

    Suspension Travel Front

    100 mm

    Suspension Travel Rear

    147 mm

  • Performance
    Brake System Front

    Disc brake 160 mm

    Brake System Rear

    Disc brake 160 mm

    Power

    Torque

  • Brakes
    Front Brake Disc Diameter

    Rear Brake Disc Diameter
