Think of the KTM 1290 SUPER DUKE GT as a comfortable ballistic missile. Powered by a 175 horsepower V-twin cranking out 141 Nm of torque, it devours provincial and border lines with minimal effort. Needless to say then, when it comes to covering ground comfortably at speed, the KTM 1290 SUPER DUKE GT is a bit of a weapon.
The KTM 1290 SUPER DUKE GT’s BEAST-derived LC8 V-Twin powerplant perfectly fits its sovereign appearance. Now with a EURO5 rating, this 173 hp, 141 Nm lump is as much a superbike slayer as it is a coastal road cruiser. A unique mix of the highest quality components, such as titanium inlet valves, have also combined to create overall reliability and allowing for service intervals of 15,000 km. That’s a lot of touring!
An absolutely key element in the outstanding performance and smooth response of the 1301 cc 75° V-twin are the unit’s cutting-edge four-valve cylinder heads. These combine twin-plug ignition, flow-optimized ports, lightweight titanium valves and resonator chambers for the smoothest twin in town.
The responsiveness and free-revving nature of the KTM 1290 SUPER DUKE GT’s engine is thanks to the low reciprocating weight of its crankshaft.
We borrowed Formula 1 technology in creating the pistons in the KTM 1290 SUPER DUKE GT. The forged piston structure, results in a high loading capacity, despite the extremely short and lightweight design. Furthermore, the piston skirts have a state-of-the-art, hard-anodized finish. Not only does this reduce friction, it is also particularly hard-wearing with a consequently a positive impact on durability.
The twin-plug ignition system controls two differently sized spark plugs in each cylinder head independently of each other in such a way that more efficient combustion and a smoother, optimally controlled combustion sequence are achieved at all times. The result: more power, better control, lower fuel consumption and lower emissions.
The ride-by-wire system on the KTM 1290 SUPER DUKE GT goes the extra mile. By electronically translating throttle commands into optimum throttle valve positions for the current riding situation, it processes throttle twist grip movements with the help of electronic sensors and activates the throttle valves accordingly using servo motors. This means smoother throttle response, reducing the chances of low-rev jolting and involuntary wheelies. Voluntary front wheel antics however, could easily be a thing of your future.
When you’re traveling two-up, the last thing you want is a jerky throttle. KTM have worked the EFI mapping, in combination with the plain bearing and timing, to transfer low-down power to the road with less vibration and reduced engine noise.
Not only does the slipper clutch open when the engine back-torque becomes too high, it also assists when you open up the throttle. The former prevents destabilizing rear wheel chatter when braking sharply or decelerating; the latter reduces the hand force required for changing gear, allowing the clutch to be controlled with one trigger happy finger.
The KTM 1290 SUPER DUKE GT’s exhaust system is made entirely from rustproof stainless steel and is EURO5 homologated. Hundreds of test bench runs and complex simulations ensured that the exhaust system, which is using an exhaust flap, contributes decisively to the extremely smooth torque curve and excellent emission values of the powerful twin-cylinder. And did we mention the sound? While it whispers at low revs, it will take your breath away reaching for the high notes.
The hint is in the name. The KTM 1290 SUPER DUKE GT is built for covering ground quickly and comfortably. Thanks to its refined ergonomics, electronically adjustable suspension and impressive tank range, the KTM 1290 SUPER DUKE GT is the perfect travel companion.
Engineered to support a pillion, as well as full-loaded panniers, the subframe on the KTM 1290 SUPER DUKE GT ticks a number of key hyper-touring boxes.
The single-sided swingarm on the KTM 1290 SUPER DUKE GT is not only the lightest in its class, but also meticulously manufactured and generously dimensioned – a reassuring nod to spirited long distance travel.
Innovative WP semi-active suspension serves comfort, safety and adjustability on the KTM 1290 SUPER DUKE GT. This allows the rider to easily adjust suspension settings at the push of a button, with advanced sensor wizardry taking care of the details. Other than the expected “Comfort”, “Street” and “Sport” settings, the rider can also take extra pillion weight into account, with the SCU (Suspension Control Unit) adapting the damping, load and anti-dive rates in real-time. It also monitors rider position, using information provided by a set of stroke sensors and accelerometers to ensure optimal suspension performance in all conditions.
If you’ve been on the road long enough, you’ll almost definitely come across a rough patch of tarmac. Thanks to a reliable and sensitive WP steering damper fitted as standard to the KTM 1290 SUPER DUKE GT, unpleasant kick-back through the bars is significantly reduced.
All new CAD-designed 5 spoke wheels adorn the KTM1290 SUPER DUKE GT, not only looking great, but also saving nearly 1 kg of unsprung weight.
The KTM 1290 SUPER DUKE GT is equipped with brand new Continental ContiRoadAttack 4 rubber, which have been specifically developed according to KTM requirements. This means the big GT stops, turns, and grips in all road conditions exactly like a Grand Touring motorcycle should.
More than adequate deceleration is ensured at the front wheel by the two radially mounted four-piston Monoblock calipers gripping floating 320 mm discs. The spacing between hand brake lever and handlebar is adjustable so that the lever is always within easy reach for every rider. The front brake receives effective support from the disc brake on the rear wheel, which features a 240 mm diameter disc and a two-piston caliper. The enormous potential of the brakes can be exploited to the full thanks to its sportily tuned anti-lock braking system. The ABS even has a supermoto mode, for when you absolutely feel like backing it in while on holiday.
The 23 litre, long range fuel tank, in combination with the low fuel consumption of the 1290 v-twin engine, easily provides hundreds of kilometers of exciting riding without caring about a fuel station; an important benefit for touring in desolate regions. The fuel tank also protects the rider’s lower body from wind and weather for added comfort mile after mile.
An all-new full colour 7” TFT Dashboard lifted from the KTM 1290 SUPER ADVENTURE S takes the KTM 1290 SUPER DUKE GT’s dash into a different realm. Featuring a slew of features, from Turn-by-turn navigation to a dedicated PERFORMANCE MODE, the display layout finds the ultimate balance between information, performance, and style.
Arguably the most important part of the KTM 1290 SUPER DUKE GT, the handlebars give the rider complete control, from small steering inputs to adjusting the suspension and ride modes at a push of a button. Even the handlebars themselves are multi-adjustable, with over 22 mm of movement and four positions. But best yet, the KTM 1290 SUPER DUKE GT comes fitted with heated grips as standard.
All new switchgear means navigating the KTM 1290 SUPER DUKE GT’s impressive TFT functionality is effortless. A great deal of testing and development has gone into the new switch gear on the GT, making it easy for riders to adjust everything from MTC slip settings via the paddles to accessing various menus and widgets.
The KTM 1290 SUPER DUKE GT comes fitted with heated grips. Cosy.
Riders can choose three positions for the brake and shift lever to accommodate a variety of boots sizes, or to simply find their perfect shifting or braking preference.
A unique windshield design gives the rider maximum protection from the elements, and reduced wind noise at speed. An improved windscreen adjuster has also been developed, giving riders 9 positions of adjustability, while keeping one hand on the throttle.
Don’t be fooled – there is a BEAST hiding under all those touring parts. Build for comfort, speed, and long-distance travel, the GT is 100% true to its namesake – finished in exclusive GT-only graphics and paint package.
LED CORNERING LIGHTS
The KTM 1290 SUPER DUKE GT has cornering lights integrated into its fuel tank. These consist of three LED segments, using the lean angle sensor of the MSC system as a trigger. Depending on the lean angle, the KTM cornering light can use up to all three segments, always giving the rider the perfect view to where he/she is going. Integrated in the cornering lights are also LED indicators, which give the KTM 1290 SUPER DUKE GT a unique and exclusive look.
INTEGRATED PANNIER MOUNING
Hard case panniers are offered as KTM PowerParts can be easily fitted to the integrated mounting system of the motorcycle, while keeping the sporty look and unique style of the motorcycle. Remove the panniers in an instant, and instantly be badass.
A slew of advanced electronics are fitted to the KTM 1290 SUPER DUKE GT, which enable the rider to explore the GT’s full potential.
The MTC (Motorcycle Traction Control) lean-angle sensitive traction control system reacts immediately if the rotational speed of the rear wheel is disproportionate to the riding situation. In a matter of milliseconds, MTC reduces the engine output with an extremely smooth, barely perceptible intervention at the throttle valves, until the system has reduced slippage to optimum proportions for the selected ride mode and current angle of lean. Depending on the selected riding mode, MTC traction control allows different levels of traction slip at the rear wheel. In “Street mode” somewhat more than in “Rain mode”, while slight power slides are allowed when exiting curves in “Sport mode”. All this means that the rider can concentrate on the run of the road and other road users – the guarantee for maximum performance and ultimate riding pleasure, but also a decisive contribution to active safety. For particularly ambitious riders, who feel like enjoying the breathtaking propulsion of the KTM 1290 SUPER DUKE GT without any electronic assistance, the traction control can also be switched off.
The ultimate in safe deceleration. One component of the comprehensive BOSCH MSC assistance package is the lean-angle sensitive cornering ABS. Based on the high-quality 9ME modulator, it unites the talents of combined front and rear wheel braking and lightning-quick, efficient pressure modulation with the high quality BREMBO hardware to make the most advanced braking system on the market – no-one brakes more progressively or safely, even at extreme lean angles.
The GT is still part of the DUKE family. With that in mind, we have carried over “Supermoto mode” to allow keen riders to lock the rear wheel with ABS staying active on the front wheel – a prerequisite for committed cornering with the rear wheel screeching in delight.
