Model Description
Technology Data TT125 – Fuel Injection E4
Model Specification
-
Dimensions
Dimensions
1870(L) ×620(W) ×1115(H)
Wheel Base
1370mm
Dry Weight
125kg
Max Load
169kg
Ground Clearance
330mm
Seat Height
780mm
Displacement
124.6cc
Engine Type
Single Cylinder, Forced Air, SOHC, 2V
Bore / Stroke
52,4/57,8mm
Compression Ratio
10.5 / 0.2 : 1
Max net power, rate
7.0/8000
Max net torque, rate
9.67/7200
Ignition
Electronic CDI ignition
Chassis
Space frame tubular chassis with ABS cladded bodywork.
Front Suspension
Double hydraulic pre load adjustable shock absorber with coil spring with anti dive linkage system.
Rear Suspension
Coil spring with adjustable preload (4 positions) hydraulic shock absorber
Starting Method
Electric
Front Tyre
Tubeless 110/70-12
Rear Tyre
Tubeless 120/70-12
Brake
CBS combined (F) 220mm Disc/(R)Disc 200mm
Battery
12 volts
Fuel Tank Capacity
11L
Emissions Compliance
Complies with Euro 3 multi-directive
