TT125

£TBC

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry Apply for Finance

Model Description


Technology Data TT125 – Fuel Injection E4

Model Specification


  • Dimensions
    Dimensions

    1870(L) ×620(W) ×1115(H)

    Wheel Base

    1370mm

    Dry Weight

    125kg

    Max Load

    169kg

    Ground Clearance

    330mm

    Seat Height

    780mm

    Displacement

    124.6cc

    Engine Type

    Single Cylinder, Forced Air, SOHC, 2V

    Bore / Stroke

    52,4/57,8mm

    Compression Ratio

    10.5 / 0.2 : 1

    Max net power, rate

    7.0/8000

    Max net torque, rate

    9.67/7200

    Ignition

    Electronic CDI ignition

    Chassis

    Space frame tubular chassis with ABS cladded bodywork.

    Front Suspension

    Double hydraulic pre load adjustable shock absorber with coil spring with anti dive linkage system.

    Rear Suspension

    Coil spring with adjustable preload (4 positions) hydraulic shock absorber

    Starting Method

    Electric

    Front Tyre

    Tubeless 110/70-12

    Rear Tyre

    Tubeless 120/70-12

    Brake

    CBS combined (F) 220mm Disc/(R)Disc 200mm

    Battery

    12 volts

    Fuel Tank Capacity

    11L

    Emissions Compliance

    Complies with Euro 3 multi-directive
